GHP Series Multi-Cylinder High-Efficiency Cone Crusher

INTRODUCTION

Advanced Design & Simple Structure & High Technical Content & Excellent Manufacturing

The GHP series multi-cylinder high-energy cone crusher is a major leap in the structural design of cone crushers. The strong fixed shaft structure and direct punching shaft sleeve design ensure that the GHP series multi cylinder high-energy cone crusher has higher rotational speed and greater crushing capacity. The crushing chamber designed by using the theory of inter-granular crushing ensures the particle size of the product, avoids over crushing of materials, and reduces the wear of broken parts, while significantly improving production capacity. By utilizing an ultra-high pressure energy storage hydraulic system, the hydraulic safety cylinder is driven in both directions to achieve hydraulic safety and hydraulic cleaning of the crusher, as well as hydraulic locking and hydraulic motor adjustment. We simplify the equipment structure, basically eliminating accidents caused by overloading and other factors, making production operation adjustments more convenient. Maintenance and upkeep are simpler, making it a true high-energy cone crusher.

With advanced design, simple structure, high technical content, and excellent manufacturing, it is the most advanced crusher in the world today. With strong momentum, it is widely used in modern crusher production process lines with reasonable process design, strict product particle size control, high yield requirements, and advanced process control management.

The GHP series Multi-Cylinder Hydraulic Cone Crusher is designed for heavy-duty working conditions, with ultra-high stability, greatly improving production capacity and crushing efficiency. The advanced overall design of the main frame, combined with large eccentricity, high speed, and intelligent control system, demonstrates excellent crushing performance in crushing operations. Compared with other models of cone crushers, the main spindle speed is higher and the crushing force is greater, resulting in a higher content of fine particles in the discharge. It is widely used in fine crushing operations in mining and sand and gravel industries.

FEATURES

The GHP series cone crusher is equipped with an iron release hydraulic cylinder, which can quickly allow non crushable materials to pass through the crushing chamber. So as to shorten the downtime and reduce the damage of non crushable materials to the crusher;

Advanced lining plate fixing technology has improved the reliability of lining plate use. The fixed cone lining plate is engaged with the spiral inclined surface on the upper part of the fixed cone lining plate by the module, forming a self-locking mechanism; The dynamic cone lining plate is fixed by self-locking locking bolts;

The hydraulic motor drives the fixed cone to precisely adjust the ore discharge port, and can also rotate all the fixed cones out of the adjustment ring thread for easy replacement of the lining plate; Simply replace the dynamic cone lining plate, fixed cone lining plate, adapter ring, and wedge block fastening bolts to achieve arbitrary switching of the crushing chamber from standard extra coarse to short end EF; All components of the crusher are equipped with wear-resistant protection to minimize maintenance costs.
